Multilift

Value and reliability

The Multilift vertical platform lift can be customised with a variety of options to meet your shorter travel accessibility needs. Apart from an unenclosed version, the Multilift also offers an enclosed and a Mobile or 3G version. The Multilift uses constant pressure operation with controls onboard the lift as well as at each landing. It utilises a self-supporting base and tower structure which houses the mechanical components keeping them protected and simplifying the installation.

Durable wheelchair lift for commercial or residential access, available in multiple entry/exit configurations and platform sizes
Reliable, easily installed ACME screw drive lift carries a wheelchair and passenger between 2 stops, up to 1.82 m (for more stops and higher travel, see V-1504 VPL)
Nominal speed of 0.04 m/s
Gate available with aluminium, acrylic or glass inserts, and with automatic opener
Drive system housed in tower, so no machine room required; 340 kg capacity
Available as indoor or outdoor unit, enclosed and mobile
- Mobile unit provides temporary accessibility; includes 2 manual platform gates and automatic access ramp
- 3G unit structure creates a partial enclosure that does not obstruct the surrounding view

Design inspiration guide

Features
- Durable construction: Ideal for indoor use or outdoors; includes weather-resistant lock.
- Reliable operation: From the ACME screw drive with its precision movement and strength for day-to-day use.
- Easy to install: The self-enclosed drive tower makes the unit fast and easy to install.
- Mobile unit: Can be moved to provide access where needed. Includes 2 manual platform gates and automatic access ramp.
- 3G (three gate) unit: Ideal for a stage, courtroom or other public areas where you don’t want the obstruction created by a full enclosure. The fixed side walls and landing gate create a partial enclosure for safety when the lift is being used – no one can get under the lift while in use.
- Other standard features: Continuous pressure operation, keyed access on car, non-skid zinc-coated platform in three standard sizes, automatic access ramp.
- Standard finish: Beige powder-coat paint.
- Safety features: Emergency stop button on car, underpan obstruction sensors, non-skid platform, manual lowering crank, 1070 mm side panels, keyed cab buttons and keyed call stations, automatic access ramps, backup nut and backup nut safety switch.
- Warranty: 36 months parts. Ask your Savaria representative for details.
Options
- Access ramp: 406 mm, 610 mm; 36″ and 42″ wide platforms optional
- Other options: Low profile aluminium doors, steel ULC fire-rated ProDoor, wooden door, power gate and door operators; aluminium, acrylic or clear tempered laminated inserts for gate and aluminium door; WR-500 weather resistant lock; emergency light on car; fixed access ramp; commercial package (audible alarm on car, grab rail); telephone or ADA handsfree phone; joystick; 60 mm buttons; wired hand pendant. Keyless operation if desired.

Savaria Multilift Mobile vertical platform lift

Technical specifications

MODEL	CAB FLOOR AREA	EXTERIOR DIMENSIONS	LOAD	SPEED
Multilift Mobile	914 mm x 1219 mm Type 2	1070 mm (Standard Wall Height)	340 kg	0.04 m/s
Multilift Enclosed	914 mm x 1219 mm Type 2, 3, 4 914 mm x 1372 mm Type 2, 3, 4 914 mm x 1524 mm Type 2, 3, 4	1070 mm (Standard Wall Height)	340 kg	0.04 m/s
Multilift Unenclosed	864 mm x 1219 mm Type 2, 3, 4 863 mm x 1371 mm Type 2, 3, 4 863 mm x 1524 mm Type 2, 3, 4	1070 mm (Standard Wall Height)	340 kg	0.04 m/s

TRAVEL HEIGHT

Multilift Mobile	1.22 m (Max)
Multilift Enclosed	1.82 m (Max)
Multilift Unenclosed	1.82 m (Max)

INSTALLATION

76.2 mm pit depth

STOPS

2

POWER SUPPLY

120 VAC, 15 A, 60 Hz, single phase (must be a dedicated electrical line)

DRIVE SYSTEM

Acme screw and back-up nut

TECHNICAL COMPLIANCE

ASME A18.1-2003

OPERATION

constant pressure

MACHINE ROOM

roomless

USE

residential / commercial
indoor / outdoor

WARRANTY

36 months parts

Documents

Landing Doors and Locks Selection Chart

Multilift Brochure

Multilift Owner's Manual

Multilift Mobile Owner's Manual

Multilift Public Planning Guide

Multilift Residential Planning Guide

Please note, product details for Asia may vary. Please consult our sales offices for complete specifications.
